Brake Line Fitment Guide for 1970-1974 Dodge Challenger and Plymouth Barracuda

NOTE 1: This guide is intended as a reference for selecting the correct kits from our catalog but please do note that it may not be absolute and the best way to confirm information is to check the parts actually installed on your vehicle!

NOTE 2: ALL 70-74 E-Bodies with Front Drum Brakes have Valve Option Type A, See Figure 2.

NOTE 3: Our Kits are available in Steel (Lines), Rubber (Hoses), and Stainless Steel (Lines and Hoses).

To shop for these kits CLICK HERE!


Front Brake Line Kits:

  • Standard/Manual Front Drum Brakes:
      • EKT7001: 1970-1973. Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1.

      • EKT7101: 1971-1973. Right (Passenger) Front Line Routed OVER Passenger Side Frame Rail, See Figure 1.
    • Power Front Drum Brakes:
        • EKT7002: 1970-1973. Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1.
        • EKT7102: 1971-1973. Right (Passenger) Front Line Routed OVER Passenger Side Frame Rail, See Figure 1.
      • Manual/Non-Power Front Disc Brakes:
        • EKT7006: 1970-1971. Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1. Valve Option Type C, See Figure 2. CHALLENGERS REQUIRE EIN7008 AND BARRACUDAS/CUDAS REQUIRE EIN7004 FOR PROPER APPLICATION!
        • EKT7008: 1970-1971. Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1. Valve Option Type D, See Figure 2. CHALLENGERS REQUIRE EIN7007 AND BARRACUDAS/CUDAS REQUIRE EIN7003 FOR PROPER APPLICATION!
        • EKT7202: 1972-1973. Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1.
        • EKT7204: 1972-1973. Right (Passenger) Front Line Routed OVER Passenger Side Frame Rail, See Figure 1.
        • EKT7402: 1974. Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1.
        • EKT7404: 1974. Right (Passenger) Front Line Routed OVER Passenger Side Frame Rail, See Figure 1.
      • Power Front Disc Brakes:
        • EKT7003: 1970-1971. Does NOT fit with a Hemi engine! Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1. Valve Option Type D, See Figure 2. CHALLENGERS REQUIRE EIN7007 AND BARRACUDAS REQUIRE EIN7003 FOR PROPER APPLICATION!
        • EKT7007: 1970-1971. Fits with a Hemi engine only! Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1. Valve Option Type D, See Figure 2. CHALLENGERS REQUIRE EIN7007 AND BARRACUDAS REQUIRE EIN7003 FOR PROPER APPLICATION!
        • EKT7004: 1970-1971. Does NOT fit with a Hemi engine! Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1. Valve Option Type C, See Figure 2. CHALLENGERS REQUIRE EIN7008 AND BARRACUDAS REQUIRE EIN7004 FOR PROPER APPLICATION!
        • EKT7005: 1970-1971. Fits with a Hemi engine only! Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1. Valve Option Type C, See Figure 2. CHALLENGERS REQUIRE EIN7008 AND BARRACUDAS REQUIRE EIN7004 FOR PROPER APPLICATION!
        • EKT7103: 1971. Does NOT fit with a Hemi engine! Right (Passenger) Front Line Routed OVER Passenger Side Frame Rail, See Figure 1. Valve Option Type D, See Figure 2. CHALLENGERS REQUIRE EIN7007 AND BARRACUDAS REQUIRE EIN7003 FOR PROPER APPLICATION!
        • EKT7105: 1971. Fits with a Hemi engine only! Right (Passenger) Front Line Routed OVER Passenger Side Frame Rail, See Figure 1. Valve Option Type D, See Figure 2.  CHALLENGERS REQUIRE EIN7007 AND BARRACUDAS REQUIRE EIN7003 FOR PROPER APPLICATION!
        • EKT7203: 1972-1973. Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1.
        • EKT7205: 1972-1973. Right (Passenger) Front Line Routed OVER Passenger Side Frame Rail, See Figure 1.
        • EKT7403: 1974. Right (Passenger) Front Line Routed UNDER Passenger Side Frame Rail, See Figure 1.
        • EKT7405: 1974. Right (Passenger) Front Line Routed OVER Passenger Side Frame Rail, See Figure 1.

      Intermediate (Front to Rear) Brake Line Kits:

      • For Dodge Challenger Models Only:
        • EIN7007: 1970-1971 with Front Disc Brakes. Valve Option Type D, See Figure 2. OR 1970-1974 with Front Drum Brakes.
        • EIN7008: 1970-1971. Front Disc Brakes. Valve Option Type C, See Figure 2. 2 Piece Line.
        • EIN7202: 1972-1974. Front Disc Brakes.
      • For Plymouth Barracuda/Cuda Models Only:
        • EIN7003: 1970-1971 with Front Disc Brakes. Valve Option Type D, See Figure 2. OR 1970-1974 with Front Drum Brakes. 1 Piece Line.
        • EIN7004: 1970-1971. Front Disc Brakes. Valve Option Type C, See Figure 2. 2 Piece Line.
        • EIN7201: 1972-1974. Front Disc Brakes.

      Rear Axle Brake Line Kits:

      • ERA7001: 1970-1973. 8-¾ inch Rear Axle or Dana Rear Axle.
      • ERA7401: 1974. 8-¾ inch Rear Axle.

      Brake Hoses:

      • Front Hoses:
        • HSP3767: 1970-1972. Front Drums. Quantity of 2 Required!
        • HSP3498: 1970-1973. Front Disc Brakes. Quantity of 2 Required!
        • HSP5225: 1974. Front Disc Brakes. Quantity of 2 Required!
      • Rear Hoses:
        • HSP4285: 1970.
        • HSP4652: 1971. Rear Left OR Rear Right.
        • HSP4984: 1972-1974. Rear Center.

      Brake Clips:

      • HCK0001: 1970-1974. 8 Clips, 3 Bolts.

      Figures:

      • Figure 1: Under/Over
        Figure 1: Under/Over
      • Figure 2: Valve Options
        • Type A: Valve #1 (Front Drum Brakes Only!)
        • Type B: Valves #1 and #4 (Contact Us if you have this!)
        • Type C: Valves #1, #3, and #4
        • Type D: Valves #2 and #3
      Figure 2: Valve Options
